VIP - VORTAB Insertion Panel Flow Conditioner

The VIP (Vortab Insertion Panel) flow conditioner completely neutralizes flow profile irregularities caused by elbows, valves, blowers, compressors, and other flow disturbances that commonly occur in piping and duct runs and cause flow meter inaccuracies. The VIP provides a swirl-free, symmetric and repeatable flow profile that flow meters require for accurate measurement.

View More

VSR - VORTAB Short Run Flow Conditioner

The VORTAB Short Run flow conditioner (model VSR) offers a simple flow conditioning pipe section replacement for new and existing piping systems. The VSR is a three pipe diameter long flow conditioning spool piece with just the VORTAB flow conditioning internals.

View More

VIS - VORTAB Insertion Sleeve Flow Conditioner

The VORTAB Insertion Sleeve Flow Conditioner (model VIS) is the most cost effective version of the VORTAB flow conditioning products. The VIS can be installed directly into existing pipe or specially designed round, square or rectangular ducts.

View More

VEL VORTAB Elbow™ Flow Conditioner

The Vortab Elbow™ 90° long radius elbow (model VEL) flow conditioner offers a simple flow conditioning elbow replacement for new and existing piping systems. The Vortab Elbow flow conditioner is the only true isolating elbow flow conditioner in the world. It not only has the ability to isolate irregular velocity profiles and swirl normally encountered in a single elbow, but it also has the ability to isolate any irregular velocity profiles entering the Vortab Elbow.

View More

VMR - VORTAB Meter Run Flow Conditioner

The VORTAB Meter Run flow conditioner (model VMR) offers a complete, simple pipe section replacement for new and existing piping systems. The VMR is a seven pipe diameter long spool piece comprised of three pipe diameters of VORTAB flow conditioning internals and a built in downstream settling chamber.

View More

VFK VORTAB Field Kits

The VORTAB Field Kit (model VFK) flow conditioner is recommended for line sizes larger than 36”. The VFK consists of all the vortices generating flow conditioning internals and a fabrication drawing complete with welding recommendations.

View More
