NOSHOK Announces New Transmitters for the Food & Beverage Industry

in Blog
Noshok 20 Series Intelligent Silo and Tank Level Transmitter
Noshok 20 Series

AMS-IC the Australian Distributors of Noshok announces a new range of transmitters

NOSHOK announces the availability of our new 20, 25 and 30 Series Intelligent Pressure and Level Transmitters, uniquely designed to address the specific requirements of the food and beverage industry through their Australian distributor, AMS-IC. These transmitters are ideal for hygienic applications and harsh, aggressive ambient conditions.

NOSHOK 20, 25 and 30 Series Transmitters feature a superior design that positions the pressure and temperature sensors directly behind the diaphragm, which minimizes fill fluid and allows the use of a smaller diaphragm. This provides active temperature compensation at the point of measurement to minimize temperature and position error.

Turndown ratios up to 10:1 allow greater rangeability, minimising inventory requirements. Accuracies are based on percent of adjusted span, not full scale range.

Constructed of polished Stainless Steel, NOSHOK’s new intelligent transmitters feature programming via a standard onboard display with no pressure source required, and are also available with Hart® protocol. These transmitters have a

25 Series Intelligent Pressure & Level Transmitter
25 Series Intelligent Pressure & Level Transmitter

360° rotatable display for flexibility and readability in multiple mounting positions.

The new 20, 25 and 30 Series NOSHOK Transmitters meet 3A requirements.

  • Easy programming and range adjustment without test pressure via on-board display
  • Accuracy 0.1% of adjusted span
  • 10:1 turn down
  • Active temperature compensation
  • 360° rotatable display

  • Ranges from 16 inH2O to 58 psig (1,600 inH2O)
  • Output signals: 4 mA to 20 mA 2-wire, 4 mA to 20 mA 2-wire and Hart® signal
  • Hart® protocol output available
  • All Stainless Steel housing and wetted parts
  • Environmental rating IP66 (IP68 optional)
  • Strong flush diaphragm with minimal fill volume
  • Can be cleaned-in-place (CIP) or steamed-in-place (SIP)
  • Meets 3A requirements
  • Ideal for applications including food & beverage, dairy, chemical processing and pharmaceutical industries.
  • 30 Series "Snorkel" Pressure and Level Transmitter
    30 Series “Snorkel” Pressure and Level Transmitter
